[Intl_DxMedPhys] Canon Insight CT X-ray trigger to sync with physiological waveforms

[Meier, Joseph]

Hi list serv,

I have a research group who needs to sync the x-ray beam on signal with their physiological monitoring systems.  This is for dynamic airway studies on our Canon Insight scanners.  Currently, they have an optical sensor that measures when the x-ray warning light turns on, but the duration of that light is consistently 0.12 to 0.18 s longer than the RSDR exposure duration values.

Does anyone know of a way to get a trigger signal directly form the generator or from the gantry?

We have spoken with our service engineers and Canon scientists but we have not been presented with a solution yet.

Thank you,

Joe Meier



Joseph Meier, PhD

Diagnostic Imaging Medical Physicist, Cincinnati Children’s Hospital

Assistant Professor, University of Cincinnati

3333 Burnet Ave, MLC 5031

Cincinnati, OH 45229-3026

(713) 422-3597 (O)

(513) 636-7775 (Administrative Assistant)





[cid:1873ef76-bf23-4abc-a6f3-ff39b1814fe6]
